Optical Microscope

Description

Microscope is a necessary tool for mobile phone PCB inspection and BGA rework repair. It will improve your efficiency on repairing mobile phone.

Specifications

● Quality Grade: OEM New

● Magnification: 7 X-45 X

● Head Movement: X- and Y-axes

● Zoom Range: 13:1

● Field of View: 2-1/2"

● Optical working distance: Up to 8"

● Microscope Stand: Single-arm boom stand, Pillar stand.

● Illumination Type: Episcopic (reflected)

● Light Source: 80-bulb LED ring light

● Voltage: 110 V/220 V

● Plug types: EU plug; US plug; UK plug.

Features

● The professional stereo zoom microscope has a pair of 10X super wide field high eye point eyepieces, a 0.7 X-4.5 X zoom objective, a 0.5 X Barlow lens, and a

single-arm boom stand, pillar stand.

● The microscope has an overall magnification range of 7 X-45 X. The binocular viewing head has an interpupillary range of 55 to 75 mm, a 45-degree inclination

to reduce eye and neck strain, and 360-degree rotation to enable sharing.

● The WH10x20 mm super wide field high eye point eyepieces combine with the 0.7 X-4.5 X zoom objective to provide continuous zoom magnification and a

longer working distance for inspecting large-scale specimens that require handling or repair.

● The removable 80-bulb LED ring light provides bright, cool light for working with temperature-sensitive or live specimens. The ring light provides shadow-free

illumination, and a rheostat controls the amount of light emanating from the lamp.

Packing

Foam box + Carton box
